Case 37 Five canals more common than we think

Pre-operative x-ray #19

Patient presented with swelling and painful to bite.

Photo showing pulp chamber floor #19

Once the pulp chamber was clear, five canals clearly visible. Note: The fifth canal is usually in the isthmus area between distal buccal and distal lingual systems, if in the distal root.

Post-operative x-ray #19

All canals were filled to the apex.

Comments: Usually if there are five canals you will find three in the mesial root more often than the distal root. Three canals in the either root are usually not three separate canals.  In my experience, a third canal either joins the  buccal or lingual canal system.  I can tell you from surgically treating first molars, that the isthmus area many times is the cause of periapical problems because the isthmus has not been or cannot be cleaned adequately.

Case 36 Lateral canals can be important.

Preoperative x-ray #4

Tooth is symptomatic.

Immediate post operative x-ray #4

Obturation with 2 lateral canals.

2 month post operative check #4

Tooth is asymptomatic.

6 year post operative x-ray #4

Note: resorption of lateral canal filling material.  Probably just sealer only, gutta percha does not dissolve. Lateral lesions have healed.

Please note: Apical lesion on #5.

7 year post operative xray

All lesions have healed around #4 and no evidence of lateral canals being filled.  Root canal was completed on #5.

Comments:

If lateral canals are not filled i.e. cleaned, there is a good chance that a tooth's apical area will never heal.

In most cases, it is impossible to mechanically cleanse an lateral canal system. However, sodium hyperchloride may chemically clean a lateral canal. In most of my cases, if a lateral canal is filled it is with softened gutta percha and sealer.  This is speculation on my part, however.

Case 35 Apicoectomy vs. Orthograde Retreatment

Pre-operative x-ray #19

Root canal completed by another provider with separated file in ML canal.  Tooth is extremely symptomatic.

Post-operative x-ray #19

Surgical approach was decided upon and no fractures noted. Three retro fills were placed, and a separated file was removed from ML canal with ultrasonics.  Despite large size of lesion and the amount of bone loss, the prognosis was good.

3 month check-up #19

Patient is asymptomatic and healing was noted.

9 month check-up #19

Patient continues to be asymptomatic and the bone almost completely filled in

Comments:  Separated instruments are just a way of life for those who do root canal therapy.  The instrument itself is not a problem.  What it represents is: a blockage of a possible dirty canal.  In this case, I just speculated that the separated instrument was the cause of this patient's problem.  Do I know this for sure? No.  Therefore all canals were retrofilled.
